| List Price (body only) |
• £4499 (UK)
• $4999 (US)
• €4599 (EU) |
| Body material |
Magnesium alloy
(exterior, chassis and mirror
box) |
| Sensor *
|
• 27.9 x 18.6 mm CMOS sensor
• 1.3x crop factor
• RGB Color Filter Array
• Built-in fixed low-pass filter
(with self-cleaning unit)
• 17 million total pixels
• 16.1 million effective pixels
• 3:2 aspect ratio |
| Image processor
* |
Dual DIGIC 4 |
| A/D conversion |
14 bit |
| Image sizes (JPEG)
* |
• 4896x3264 (L)
• 4320x2880 (M1)
• 3552x2368 (M2)
• 2448x1632 (S)
|
| Image sizes (RAW)
* |
• 4896x3264 (RAW)
• 3672x2448 (M-RAW)
• 2448x1632 (S-RAW) |
| File formats |
• RAW (.CR2; 14-bit)
• JPEG (EXIF 2.21) - Fine /
Normal
• RAW + JPEG (separate files) |
| JPEG quality options |
Each JPEG size (L, M1, M2,
S) can be set to a quality level
of 1 to 10 (1 high compression,
low quality - 10 low
compression, high quality) |
| Movie Mode |
• MOV (Video: H.264, Sound:
Linear PCM)
• 1920 x 1080 (29.97, 25, 23.976
fps)
• 1280 x 720 (59.94, 50 fps)
• 640 x 480 (59.94, 50 fps)
• Max duration: 29min 59sec
• Max file size: 4GB
|
| Lenses |
• Canon EF lens mount (does
not support EF-S lenses)
• 1.3x field of view crop |
| Dust reduction |
• "EOS Integrated Cleaning
System" with fluorine coating
• Self-cleaning sensor unit
(filter in front of sensor
vibrates at high frequency at
start-up and shutdown - can be
disabled)
• Dust Delete Data - Data from a
test shot is used to 'map' dust
spots and can be later removed
using Canon DPP Software
|
| Auto focus
* |
• 45-point TTL
• 39 cross-type points, require
F2.8 or faster lens
*
• TTL-AREA-SIR with a CMOS
sensor
• AF working range: -1.0 to 18
EV (at 23°C, ISO 100) |
| Focus modes |
• One shot AF
• AI Servo AF
• Manual focus |
| AF point selection
* |
• Auto
• Manual: Single point AF (45,
19, 11 or 9 points selectable)
• Manual: Spot AF (with
compatible lens)
• Manual: AF point Expansion (Left
right,surround, all 45)
• AF points can be selected
separately for vertical and
horizontal shooting |
| AF assist |
External Speedlite only
|
| Exposure modes |
• Program
• Aperture-priority
• Shutter-priority
• Manual
• Bulb |
| Metering |
• 63 zone metering linked to
all AF points
*
• Metering range: 0 - 20 EV
• Modes: Center, Linked to AF
point, Multi-spot (up to 8
readings) |
| Metering modes |
• Evaluative (63 zone linked
to active AF point)
• Partial (13.5% of viewfinder)
*
• Spot metering (3.8% of
viewfinder)
|
| AE lock |
• Auto: One Shot AF with
evaluative metering
• Manual: AE lock button |
| Exposure compensation |
• +/- 3.0 EV
• 0.3 or 0.5 EV increments |
| Sensitivity |
• ISO 100 - 12800
• 0.3 or 1.0 EV increments
• ISO 50 (Enhanced L)
• ISO 25600 (Enhanced H1)
• ISO 51200 (Enhanced H2)
• ISO 102400 (Enhanced H3) |
| Shutter |
• Focal-plane shutter
• 30 - 1/8000 sec
• 0.3, 0.5 or 1.0 EV increments
• Flash X-Sync: 1/300 sec
(EX series Speedlites only)
• Bulb |
| Noise reduction |
• Long exposure (1 sec or
longer)
• Optional for High ISO (4
settings) |
| White balance |
• Auto (using the imaging
sensor)
• Daylight
• Shade
• Cloudy
• Tungsten
• Fluorescent
• Flash
• Custom (up to 5 can be stored)
• Kelvin (2500 - 10000 K in 100
K steps) |
| WB bracketing |
• +/-3 levels
• 3 images
• Blue / Amber or Magenta /
Green bias
|
| WB shift |
• Blue (-9) To Amber (+9)
• Magenta (-9) to Green (+9) |
| Picture style |
• Standard
• Portrait
• Landscape
• Neutral
• Faithful
• Monochrome
• User def. 1
• User def. 2
• User def. 3 |
| Color space |
• sRGB
• Adobe RGB |
| Viewfinder |
• Eye-level pentaprism
• 100% frame coverage
• Magnification: 0.76x
(-1 diopter with 50 mm lens at
infinity)
• Eyepoint: 20 mm
• Dioptric adjustment: -3 to +1
diopter
• Precision matte screen Ee-C IV
(interchangeable)
• Eye-piece shutter available
via lever |
| Mirror |
• Quick-return half mirror (transmission:reflection
ratio 37:63)
• Mirror lock-up (once or
multiple exposures) |
| Viewfinder info |
• AF points
• Focus confirmation light
• Metering mode
• Spot metering area
• Shutter speed
• Aperture
• Manual exposure
• AE lock
• ISO speed
• Exposure level
• Exposure warning
• Flash ready
• FP flash
• FE lock
• Flash exposure level
• JPEG recording
• RAW recording
• Number of remaining shots
• Maximum burst (2 digit
display)
• Highlight tone priority(D+)
• White balance correction
• Memory card information
• Battery check icon |
| LCD monitor
* |
• 3.0" TFT LCD
• 920,000 pixels
• 160° angle of view
• 7 brightness levels
• Anti-reflection |
| LCD Live view
* |
• Live TTL display of scene
from CMOS image sensor
• 100% frame coverage
• 30 frames per second
• Real-time evaluative metering
using CMOS image sensor
• Best view or exposure
simulation
• Grid optional
• Histogram
• Magnify optional (5x or 10x at
AF point)
• Quick- or Live mode AF |
| Flash |
• No built-in flash unit
• E-TTL II auto flash / metered
manual
• Flash compensation +/-3.0 EV
in 0.3 or 0.5 EV increments
• X-Sync: 1/300 sec (EX series
Speedlites only)
• Hot-shoe & PC Terminal |
| Drive modes |
• Single
• Silent (single frame)
• High-speed continuous: 10 fps
• Low-speed continuous: 3 fps
• Self-timer: 2 or 10 sec (3 sec
with mirror lock-up) |
| Burst buffer
* |
• Large/Fine JPEG: 121
frames
• RAW: 28 frames |
| Orientation sensor |
Yes |
| Custom functions
* |
62 custom functions |
| Menu languages
* |
• English
• German
• French
• Dutch
• Danish
• Portuguese
• Finnish
• Italian
• Norwegian
• Swedish
• Spanish
• Greek
• Russian
• Polish
• Czech
• Hungarian
• Romanian
• Ukrainian
• Turkish
• Arabic
• Thai
• Simplified Chinese
• Traditional Chinese
• Korean
• Japanese |
| Wireless |
Via WFT-E2/E2 II(optional)
|
| Connectivity |
• USB 2.0 Hi-Speed
• Video out
• HDMI mini output
*
• External microphone
*
• N3 type wired remote control
• PC Sync flash terminal |
| Storage |
• Compact Flash Type I or II
(supports UDMA)
• SD card slot (supports SD/SDHC)
• External USB hard drives (requires
WFT-E2/E2A) |
| Power |
• Lithium-Ion LP-E4
rechargeable battery (supplied &
charger)
• AC adapter |
| Dimensions
* |
156 x 156.6 x 80 mm (6.2 x
6.2 x 3.1 in) |
| Weight (no battery)
* |
