| List price (body only) |
US: $7,999
EU: 7,999 |
| Body material |
Magnesium alloy (exterior, chassis and mirror
box) |
| Sensor * |
36 x 24 mm CMOS sensor
Full 35 mm size frame
RGB Color Filter Array
Built-in fixed low-pass filter (with self-cleaning
unit)
21.9 million total pixels
21.1 million effective pixels
6.4 ΅m pixel pitch
3:2 aspect ratio |
| Image processor *
|
Dual DIGIC III |
| A/D conversion *
|
14 bit |
| Image sizes (JPEG) *
|
5616 x 3744 (L; 21.0 MP)
4992 x 3328 (M1; 16.6 MP)
4080 x 2720 (M2; 11.0 MP)
2784 x 1856 (S; 5.2 MP) |
| Image sizes (RAW) *
|
5616 x 3744 (RAW; 21.0 MP)
2784 x 1856 (sRAW; 5.2 MP) |
| File formats |
RAW (.CR2; 14-bit)
JPEG (EXIF 2.21) - Fine / Normal
RAW + JPEG (separate files) |
| File sizes (approx.) *
|
JPEG L: 6.4 MB
JPEG M1: 5.2 MB
JPEG M2: 3.9 MB
JPEG S: 2.2 MB
RAW: 25.0 MB
sRAW: 14.5 MB |
| JPEG quality options |
Each JPEG size (L, M1, M2, S) can be set to a
quality level of 1 to 10 (1 high compression, low
quality - 10 low compression, high quality) |
| Lenses |
Canon EF lens mount (does not support EF-S
lenses)
No field of view crop (1.0x) |
| Dust reduction *
|
"EOS Integrated Cleaning System"
Self-cleaning sensor unit (filter in front of
sensor vibrates at high frequency at start-up and
shutdown - can be disabled)
Dust Delete Data - Data from a test shot is used
to 'map' dust spots and can be later removed using
Canon DPP Software |
| Auto focus |
45-point TTL
19 cross-type points, require F2.8 or faster lens
*
Center cross-type point requires F4.0 or faster
lens
26 assist points, require F5.6 or faster lens
*
TTL-AREA-SIR with a CMOS sensor
AF working range: -1.0 to 18 EV (at 23°C, ISO 100) |
| Focus modes |
One shot AF
AI Servo AF
Manual focus |
| AF point selection |
Auto
Manual (all 19 or inner 9 / outer 9) |
| AF assist |
External Speedlite only
|
| Exposure modes |
Program
Aperture-priority
Shutter-priority
Manual
Bulb |
| Metering |
63 zone metering linked to 19 AF points
*
Metering range: 0 - 20 EV
Modes: Center, Linked to AF point, Multi-spot (up
to 8 readings) |
| Metering modes |
Evaluative (63 zone linked to active AF point)
Center-weighted average
Partial (8.5% of picture area)
Spot metering (2.4% of picture area)
|
| AE lock |
Auto: One Shot AF with evaluative metering
Manual: AE lock button |
| Exposure compensation |
+/- 3.0 EV
0.3 or 0.5 EV increments |
| Exposure bracketing |
2, 3, 5 or 7 shots
+/- 3.0 EV
0.3 or 0.5 EV increments |
| Sensitivity |
ISO 100 - 1600
0.3 or 1.0 EV increments
ISO 50 (Enhanced L)
ISO 3200 (Enhanced H) |
| Shutter |
Focal-plane shutter
300,000 exposure durability *
30 - 1/8000 sec
0.3, 0.5 or 1.0 EV increments
Flash X-Sync: 1/250 sec
Bulb |
| Aperture values |
F1.0 - F91
0.3, 0.5 or 1.0 EV increments
Actual aperture range depends on lens used |
| Noise reduction |
Long exposure (1 sec or longer)
Optional for High ISO (default Off)
* |
| White balance |
Auto
Daylight
Shade
Cloudy
Tungsten
Fluorescent
Flash
Custom (up to 5 can be stored)
Kelvin (2500 - 10000 K in 100 K steps)
Personal WB (up to 5 can be preset in software
*) |
| WB bracketing |
+/-3 levels
3 images
Blue / Amber or Magenta / Green bias
|
| WB shift |
Blue (-9) To Amber (+9)
Magenta (-9) to Green (+9) |
| Picture style * |
Standard
Portrait
Landscape
Neutral
Faithful
Monochrome
User def. 1
User def. 2
User def. 3 |
| Custom image parameters *
|
Sharpness: 0 to 7
Contrast: -4 to +4
Saturation: -4 to +4
Color tone: -4 to +4
B&W filter: N, Ye, Or, R, G
B&W tone: N, S, B, P, G |
| Color space |
sRGB
Adobe RGB |
| Viewfinder |
Eye-level pentaprism
100% frame coverage
Magnification: 0.76x *
(-1 diopter with 50 mm
lens at infinity)
Eyepoint: 20 mm
Dioptric adjustment: -3 to +1 diopter
Precision matte screen Ee-C IV (interchangeable)
Eye-piece shutter available via lever |
| Mirror |
Quick-return half mirror (transmission:reflection
ratio 37:63)
Mirror lock-up (once or multiple exposures) |
| Viewfinder info |
AF points
Focus confirmation light
Metering mode
ISO sensitivity *
Shutter speed
Aperture
Manual exposure
AE Lock
Exposure compensation amount
AEB level
Spot metering circle
Flash ready
Red-eye reduction lamp on
High-speed sync
FE Lock
Flash compensation amount
Warnings
Maximum burst for continuous shooting
Buffer space |
| LCD monitor * |
3.0" TFT LCD
230,000 pixels
7 brightness levels |
| LCD Live view * |
Live TTL display of scene from CMOS image
sensor
100% frame coverage
Real-time evaluative metering using CMOS image
sensor
Best view or exposure simulation
Grid optional (thirds)
Magnify optional (5x or 10x at AF point)
Aspect ratio masking for 6:6, 3:4, 4:5, 6:7, 10:12
and 5:7
Remote live view using EOS Utility 2.0 (via USB or
WiFi/Ethernet using WFT)
Manual focus only |
| Record review |
Off
On (histogram via INFO button)
Display mode same as last used Play mode
2 / 4 / 8 sec / Hold |
| Playback modes *
|
1. Single image with exposure, file number,
storage slot
2. As 1 but also image count and quality
3. Detailed exposure information, thumbnail and
luminance histogram
4. Less detailed exposure info., thumbnail,
luminance and RGB histograms
|
| Playback features |
Optional blinking highlight alert
Optional AF point display
Magnified view (up to 10x)
2x2 or 3x3 thumbnail index
Jump (by 1, 10, 100 images / by screen, date or
folder) *
Delete / Protect
Record audio clip up to 30 seconds |
| Flash |
No built-in flash unit
E-TTL II auto flash / metered manual
Flash compensation +/-3.0 EV in 0.3 or 0.5 EV
increments
X-Sync: 1/250 sec
High-speed flash with EX-series speedlites up to
1/8000 sec
Hot-shoe & PC Terminal
|
| Drive modes |
Single
Silent (single frame) *
High-speed continuous: 5 fps *
(adjustable 5 - 2 fps)
Low-speed continuous: 3 fps *
(adjustable 4 - 1 fps)
Self-timer: 2 or 10 sec (3 sec with mirror
lock-up) |
| Burst buffer * |
Large/Fine JPEG: 56 frames
RAW: 12 frames
RAW+JPEG: 10 frames |
| Orientation sensor |
Yes |
| Auto rotation * |
On (recorded and LCD display)
On (recorded only)
Off |
| Custom functions *
|
57 custom functions in 4 groups
|
| My Menu * |
Up to six menu options can be customized |
| Menu languages *
|
English
German
French
Dutch
Danish
Portuguese
Finnish
Italian
Norwegian
Swedish
Spanish
Greek
Russian
Polish
Simplified Chinese
Traditional Chinese
Korean
Japanese |
| Firmware |
User upgradable |
| Wireless |
Via WFT-E2/E2A (optional) |
| Connectivity |
USB 2.0 Hi-Speed *
Video out
N3 type wired remote control
PC Sync flash terminal |
| Storage |
Compact Flash Type I or II (supports UDMA)
*
SD card slot (supports SD/SDHC)
*
External USB hard drives (requires WFT-E2/E2A)
*
Canon Original Data Security Kit supported
("Original Image Data") |
| Storage options *
|
Record to one memory card
Record same image to both CF and SD cards (backup)
Record RAW image to CF and JPEG to SD card
Overflow (once one card becomes full camera uses
next card)
Copy from one card to another
|
| Power |
Lithium-Ion LP-E4 rechargeable battery
* (supplied & charger)
AC adapter |
| Power information |
Current power source
Remaining capacity
Current shutter count on this battery charge
Recharge performance |
| Dimensions * |
150 x 160 x 80 mm (6.1 x 6.2 x 3.1 in) |
| Weight (no batt) *
|
1205 g (2.7 lb) |
| Weight (inc. batt) *
|
1385 g (3.1 lb) |
