Canon Eos 1 n RS ( 1994 ) The EOS-1N was designed to build on the strengths of the EOS-1, a camera that revolutionised the professional market, and to incorporate new technologies and design concepts to fill professionals' wish lists. One of its many advanced features is a five-point autofocus using a new high-precision Multi-BASIS (Base-Stored Image Sensor) for wide-area coverage. In addition, Canon's advanced design philosophy allows every aspect of the EOS system to be upgraded, including lenses, flash units, interchangeable backs and more. So the entire system will always be on the cutting edge of photographic excellence.

Canon Eos 1V ( 1999 ) Type 35mm AF/AE single lens reflex camera with focal plane shutter (vertical travel) and built in motor drive. Compatible Lens Canon EF lenses Lens Mount Canon EF mount Viewfinder Type SLR Type, fixed eye-level pentaprism (with condenser lens) Magnification 0.72x (with 50mm lens at infinity,-1 diopter) Standard Diopter -1 diopter.Adjustable from -3 diopter to +1diopter. Picture Coverage 100% both vertically and horizontally Focusing Screen Interchangeable, Laser matte screen with Area AF ellipse, focusing points, and fine spot metering circle provided as the standard screen. Autofocus The mode can be switched between the following three: Al Servo AF Constantly tracks subject movement up to the start of exposure.Whilte the shutter is pressed halfway, the shutter button can be depressed fully at anytime to release the shutter regardless of focus.(Shutter release priority) (In the other metering modes, exposure metering continues in real-time until the shutter is released) One Shot AF Autofocus locks when focus is achieved.AF-priority: The shutter can only be released when focus is achieved.During evaluative metering, AE lock is set at the same time as AF lock. When the shutter button is pressed completely without pressing it halfway first, the shutter is released after AF operation is executed once. During continuous shooting of a moving subject, the lens is driven (taking 0 to 250 ms) from the second successive frame to track the subject, then the shutter is released. Manual Focusing: MF mode enables manual focusing with focusing ring. When focus is achieved, the in-focus indicator and superimposed focusing point light up.If focus fails, neither is displayed. During continuous shooting, electronic-ring manual focusing is enabled during film advance and disabled during exposure. Autofocus Type TTL-SIR (Through the Lens Secondary Image Registartion) with CMOS sensor Autofocus Working Range EV 0-18 (at ISO 100) Autofocus Assist Beam With an EOS Speedlite attached (with built in AF assist light) and turned on, a near-infrared beam is emitted automatically by the Speedlite when necessary. Metering Modes TTL metering at the max. Aperture with a 21 zone silicon photocell sensor. The following 6 metering modes can be selected: 1. Evaluative (linkable to any focusing point) 2. Partial Metering area: Approx 8.5% of screen 3. Center spot metering Metering area: Approx 2.4% of screen 4. Focusing point-linked spot metering: Metering area: Approx 2.4% of screen,fixed at center during automatic focusing point selection. 5. Multi-spot metering Enables up to 8 spot metering readings 6. Centerweighted averaging metering Metering Range Metering range: EV 0-20 in all metering modes Auto Exposure Lock Auto AE lock In one shot AF mode with evaluative metering, AE lock is set when focus is achieved. Manual AE lock Set with the AE lock button. Enabled in all metering modes. Exposure Modes The following 8 AE modes and manual mode can be set: 1. Shutter speed-priority AE 2. Aperture-priority AE 3. Depth of field AE With a manually selected focusing point:The selected focusing point can be used to set the two DEP points. When a pair of manually selected focusing points is selected automatically, the focusing point focused at the closer distance is used to set the two DEP points. With an automatically selected focusing point: The center focusing point is used to set the two DEP points. 4. Program AE 5. ETTL-AE program flash AE 6. ATTL-AE program flash AE 7. TTL program flash AE 8. Bulb Shooting Data When a picture is taken, the shooting data is automatically recorded in the camera's built in memory. With the EOS link software, the data can be transferred to a personal computer for viewing and editing. Viewing and editing the shooting data Enabled only with the EOS link software and a personal computer Data configuration Recording of data options is optional using the EOS link software to select items for recording Data recording timing Film data: Recorded when the film is loaded and advanced to frame 1. Shooting data: Recorded when the shutter button is pressed completely. Number of rolls recordable 50 to 200 36-ex rolls Memory check While the Assist button is active the shooting data memory mode, the LCD panel displays the remaining number of data recordable 36-ex rolls. Multiple Exposures Maximum of 9 exposures per frame Film Speed Setting ISO 25-5000 with DX coded film, set automatically in 1/3 steps ISO 6-6400 manual setting in 1/3 steps Exposure Compensation AEB Autoexposure bracketing. The bracketing sequence is correct exposure, underexposure, and overexposure, taken according to the film advance mode. Manual Exposure Compensation: Up to 3 stops in 1/3 increments Auto Exposure Bracketing Amount: Up to 3 stops in 1/3 stop increments Film Transport Type Autoloading with a sprocketless system Film Loading Automatic take up with a fixed spool Film Rewind System Automatic film rewind with a small coreless motor. Midroll Film Rewind Confirmable with the bars and frame counter on the LCD panel. Flash Control System FE lock: With E-TTL autoflash Speedlites, FE lock is set with the FE lock button Wireless Flash: Enabled. With the 550EX, MR-14EX or ST E2, those Speedlites set as slave units will fire a preflash and meter the light reflected off the subject with the AE metering sensor. The flash output is then set and stored in memory and wireless flash is fired. Flash Contact 1 Hot Shoe:Sync contacts 2 Side terminal:Threaded sync terminal Hot Shoe: Locking pin hole provided to prevent Speedlite slippage. Flash Exposure Compensation 1 Manual setting I Increments: 3 stops in 1/3 stop increments 2 FEB (Flash Exposure Bracketing) Enabled and set with the 550EX, MR-14EX ring flash Custom Functions 20 user selectable custom functions Personal functions Custom functions settable in 3 different ways and by EOS link software Clear button Pressing this button resets the settings to default as listed Self-timer 10 or 2 sec delay Power Source 2CR5 x1 Dimensions 161 (W) x 120.8 (H) x 70.8 (D) mm Weight 950g (add 40g for lithium battery) Film ID Imprinting (Built in with EOS1Vs camera back) Imprint confirmation During imprinting, the ID symbol is displayed on the LCD panel Imprinting method After the film loads, a minilamp imprints transparent LCD digits on the film base Imprinted Information User selectable two digit number (00-99) and 3 digit film ID No. (001-999) Focusing Points 45 point Area AF, 8mm (vertical) x 15mm (horizontal). The 7 vertical focusing points at the center are cross type sensors which are also vertical line sensitive. Film Advance System Automatic film advance with a small coreless motor dedicated to film transport. Film perforation detected with an infrared photo reflector. Film Advance Modes Single frame advance or continuous advance set automatically according to the picture taking and film advance mode Shutter Speed 30 to 1/8000 sec, bulb,X sync at 1/250 sec Shutter Type Vertical travel, focal plane shutter with all speeds electronically controlled. Front and rear shutter curtains both have dedicated rotary magnet control.

Canon Eos 3 ( 1998 ) The EOS 3's AF system, uses 45 focusing points for more accurate subject capture. This feature when combined with a high precision focusing system, faster eye control and improved high speed focus as well as compatibility with over 50 EF lenses and accessories means that the EOS3 is the ultimate camera for advanced amatuers and professionals alike.

Canon EOS Digital 30 ( 2000 ) Type Single-lens reflex AE-AF digital camera with built-in flash and focal plane shutter (vertical travel), 36-bit full color (RGB each 12-bit), single-shot CMOS direct imaging sensor Picture size: 22.7 x 15.1 mm (0.89 x 0.59 in) Compatible lenses: Canon EF lens group Lens mount: Canon EF mount Lens focal length: Approx. 1.6x indicated lens focal length Imaging Element Type: High-sensitivity, high-resolution, large single-plate CMOS sensor Effective Sensor Size: 22.7 x 15.1 mm (0.89 x 0.59 in) (Advanced Photo System C print type equivalent) Pixel Count: Effective: approx. 3.11 million pixels (2160 x 1440) Total: approx. 3.25 million pixels (2226 x 1460) Aspect Ratio: 2 : 3 Colour Filter Method: Primary colour filter Low-Pass Filter: Positioned on front surface of imaging element, non-removable LCD Monitor Type: TFT-type color LCD monitor Picture Size: 1.8-inch Pixel Count: Approx. 114,000 pixels Brightness adjustment: 2 levels: Standard or Bright (select by menu function) Recording Method Recording Media: CF card (Type I or II) Recording Format Type: Design rule for Camera File System Recording Formats: JPEG, RAW Recording Capacity: (1)Large/Fine: 12, (2) Large/Normal: 22, (3) Small/Fine: 22, (4) Small/Normal: 40, RAW:4 (WITH 16-mBYTE cf CARD) Parameters: Standard parameters plus three types of custom parameters selected by the user Viewfinder Type: Eye-level type with pentaprism Standard diopter: -1 dpt (eye relief 20 mm) Diopter adjustment range: -3 to +1 dpt Picture coverage: 95% vertically and horizontally Magnification: 0.88x (at -1 dpt, 50mm lens, at infinity) Viewfinder information: Shutter speed, aperture value, FEL indicator, AE/FE lock, focusing point indicator exposure level, AE exposure compensation amount, flash exposure compensation amount, manual exposure level, AEB level. Elapsed time of red-eye reduction lamp operation, flash ready, high-speed sync, AF/MF in-focus indicator Mirror: Quick-return half mirror (mirror blackout: none up to EF 600mm F4L IS USM lens) Depth of field preview: Press depth-of-field preview button Autofocus AF Type: Multi-BASIS TTL-CT-SIR type (TTL secondary image registration) Focusing points: 3-point ( + ) AF working range EV2 to EV18 (ISO 100) Focusing point selection (1) Automatic selection by camera, (2) Manual 1-point selection Focusing modes 1: One-shot AF: AF locks when focus is achieved. Shutter can be released only when focus is achieved. Focusing modes 2: AI servo AF: Tracks subject movement until the actual start of metering; includes predictive function; shutter can be released anytime regardless of focus (predictive drive has priority in continuous shooting), indicator blinks at Focusing modes 3: AI focus AF: Automatically switches between One-shot AF mode and AI Servo AF Focusing modes 4: Manual focus: When focusing mode switch on lens is set to MF (or M), manual focusing ring can be used AF-assist light: Lamp illumination type. Built-in AF-assist light emitted automatically according to conditions. Effective distance: approx. 3.8 m (12.5 ft.) from centre of viewfinder. Exposure Contol Method: 35-zone SPC and TTL open metering Method: (1) Evaluative metering Method: (2) Center partial metering (approx. 9.5% of viewfinder area) Method: (3) Center-weighted average value metering Exposure modes: (1) Program AE (shiftable) (2) Shutter speed-priority AE (3) Aperture-priority AE (4) Auto depth-of-field priority AE (5) Full Auto mode (6) Program AE Image Control modes (five types: Portrait/Landscape/Close-up/Sports/Night scene) (7) Manual (8) E-TTL autoflash program flash AE (High-speed sync, FE lock) Metering range: EV2 to EV20 (at room temperature with 50mm F1.4 lens at ISO 100) ISO speed range: Equivalent to 100, 200, 400, 800, 1600 Exposure compensation 1) AEB: ±2 stops in 1/2- or 1/3-stop ncrements, Correct exposure, underexposure, overexposure (2) Manual compensation: ±2 stops in 1/2- or 1/3-stop increments AE Lock: (1) Auto AE lock, (2) Press AE Lock button: Center partial metering and AE lock Power Supply Battery: Operates from one BP-511 Battery Pack (lithium ion battery) Number of images that can be taken (with a fully-charged battery) Power-saving functions: Set by menu function Battery check: 3-stage battery check icon on LCD panel 680 (No flash, normal temperature) 480 (No flash, low temperature) 540 (50% flash, normal temperature) 400 (50% flash, low temperature) Backup battery: One CR2025 lithium button battery (stores settings for menu functions) Backup battery warning: Change message displayed on LCD panel Camera Body Flash contacts: 1) Accessory shoe: X-sync contacts (2) Sync terminal (with locking thread) on lower corner of camera body External flash system Compatibility: Compatible with E-TTL auto sync Red-eye reduction function: Built-in flash illumination type, switches On/Off in all modes Interfaces: USB/CF card slot (Type I, II)/Video output (NTSC/PAL) Remote jack: N3 type Dimensions (W x H x D): 149.5 x 106.5 x 75 mm (5.89 x 4.19 x 3.0 in) Weight: 780 g (1.65 lb) (excluding battery pack, CF card, backup battery) Operating temperature range: 0°C to +40°C (32°F to 104°F) Operating humidity range: 85% or lower CA-PS400 Compact Power Adapter Compatible battery: Battery pack BP-511 Compatible DC coupler: DR-400 Battery mounts: 2 (Battery packs cannot be charged when the DC coupler is connected) Power cord length: Approx. 1.8 m (5.9 ft) Charging time: Approx. 90 minutes per battery pack Rated input/frequency: 100-240 V AC, 50/60 Hz Rated output: Charging: 8.4 V DC. When the coupler is connected: 8.1 V DC Operating temperature: 0°C to +40°C (32°F to 104°F) Operating humidity range: Less than 85% Dimensions (W x H x D): 100 x 51 x 133 mm (3.94 x 2.0 x 5.24 in) Weight: 285 g (10.1 oz) (when the cord is not connected) DR-400 DC Coupler Compatible adapter: Compact power adapter CA-PS400 Compatible camera: EOS D30 Rated input voltage: 6.3 to 10.5 V DC Rated output voltage: 6.3 to 10.5 V DC Cord length: Approx. 1.8 m (5.9 ft) Operating temperature: 0°C to +40°C (32°F to 104°F) Operating humidity range: Less than 85% Dimensions (W x H x D): 38.4 x 21 x 55.3 mm (1.51 x 0.83 x 2.18 in) Weight: 110 g (3.9 oz) Built-in Flash Type: Retractable E-TTL autoflash and auto pop-up flash Guide No: 12/39 (at ISO 100, m/ft.) Flash ready indicator: Flash ready icon lights in viewfinder Flash coverage: Covers field equivalent to a focal length of 18mm Flash adjustment: E-TTL autoflash (preflash for metering and focus) Flash level control: Automatic reduction in backlit conditions or for fill flash Exposure compensation: ±2 stops in 1/2- or 1/3-stop increments Focusing Modes 1: One-shot AF: AF locks when focus is achieved. Shutter can be released only when focus is achieved. 2: Al servo AF: Tracks subject movement until the actual start of metering; inludes predictive function; shutter can be released anytime regardless of focus (predictive drive has priority in continuous shooting), indicator blinks at 3: Al focus AF: Automatically switches between One-shot AF mode and Al Servo AF 4: Manual Focus: When focusing mode switch on lens is set to MF (or M), manual focusing ring can be used.AF-assist light: LAmp illumination type. Built-AF assist light emitted automatically according to conditions. Effective distance: approx. 3.8 m (12.5 ft.) from centre of viewfinder Shutter Type: Vertical-travel focal-plane shutter with all speeds controlled electronically Shutter speeds: 1/4000 to 30 sec., bulb, and X-sync at 1/200 sec. Shutter release: Soft-touch electromagnetic release Self-timer: Electronically controlled, 10-second delay Drive Drive Modes: 1: Single shot 2: Continuous 3: Self-timer (10 sec.) Number of continuous images:Approximately 3 images/second to a maximum of 8 images (ONE, SHOT, in Large/Fine format) Playback and Erase Functions Playback Modes: 1: Single image 2: Index display 3: Enlargement 4: Auto playback Erase: 1: Single image 2: All (except protected images) White Balance Type: Automatic white balance using imaging element Setting method: (1) Automatic setting, (2) Manual setting Manual white balance: Available (set from Menu function)

Specification Camera Type Digital AF SLR (CCD sensor / Direct imaging) Recording medium Type I and II CF card Image format 28.7 x 19.1 mm Compatible lenses Canon EF lenses Lens mount Canon EF lens mount Lens focal length conversion factor* Approx. 1.3 x of indicated lens focal length (*compared to 35mm format) Imaging Element Type High-sensitivity, high-resolution, large-area single-plate CCD sensor Pixels Effective pixels: Approx. 4.15 megapixels (2496 x 1665) Aspect ratio 2:3 Color filter system RGB primary colors Low-pass filter Located in front of the CCD sensor, fixed Recording System Recording format Design rule for Camera File system Image format JPEG and RAW, 36-bit true color (12 bits/ RGB color), RAW + JPEG simultaneous recording Provided file size (1) Large/Fine: approx. 2.4 MB (2464 x 1648 pixels) (2) Large/Normal: approx. 1.3 MB (2464 x 1648 pixels) (3) Small/Fine: approx. 1.1 MB (2464 x 1648 pixels) (4) RAW: approx. 4.8 MB (2496 x 1662 pixels) * Exact file sizes depend on the subject and ISO speed. Folders Folder creation and selection possible File numbering Consecutive numbering Auto reset Manual reset Image-Processing Parameters Standard parameters plus up to three custom image processing parameter sets can be set Interface IEEE 1394 (with dedicated cable) White Balance 10 Settings Auto, daylight, shade, overcast, tungsten light, fluorescent light, flash, custom, manual color temperature setting, personal white balance Auto white balance Hybrid auto balance with the CCD sensor and a dedicated, external sensor Personal white balance Up to three personal white balance settings can be registered Color temperature compensation White balance bracketing: +/- 3 steps in whole step increments (1 step = 5 mireds) Color Matrix Type 5 color matrix settings for color spaces compatible with sRGB and Adobe RGB 1998 (4 settings for standard sRGB color space) Viewfinder Type Glass pentaprism, eye-level type with eyesight correction Coverage 100% vertically and horizontally with respect the effective pixels Magnification 0.72x (-1 diopter with 50mm at infinity) Eyepoint 20 mm Built-in dioptic correction -3.0 — +1.0 diopter Focusing screen Interchangeable (9 types)Standard focusing screen: Ec-CIII Mirror Quick-return half mirror (Transmission: reflection ratio of 63:37, no mirror cut off with EF 1200mm f/5.6 or shorter lens) Viewfinder Information AF information (AF points, focus confirmation light), exposure information (shutter, speed, aperture, manual exposure, metering range, ISO speed, exposure level, exposure warning), flash information (flash ready, FP flash, FE lock, flash exposure level), JPEG format, number of remaining shots,CF card information Depth-of-field preview Enabled with depth-of-field preview button Eyepiece shutter Built-in Autofocus Type TTL-AREA-SIR with CMOS sensor AF Frame 45-point Area AF (W x H: 15mm x 8mm) AF working range EV 0-18 (at ISO 100) Focusing modes One-Shot AF AI Servo AF Manual focusing (MF) AF point selection Automatic selection, manual selection, home position (switch to registered AF point) Selected AF point display Superimposed in viewfinder and indicated on top LCD panel AF-assist beam Emitted by the dedicated Speedlite’s built-in AF-assist beam Exposure Control Metering modes TTL full aperture metering with 21-zone SPC (1) Evaluative metering (linkable to any AF point) (2) Partial metering (approx. 13.5% of viewfinder at center) (3) Spot metering a. Center spot metering (approx. 3.8% of viewfinder at center) b. AF point-linked spot metering (approx. 3.8% of viewfinder at center) c. Multi-spot metering (Max. 8 spot metering entries) (4) Centerweighted average metering Metering range EV 0-20 (at 20 °C/68 °F with 50mm f/1.4 lens, ISO 100) Exposure control systems Program AE (shiftable), shutter-priority AE, aperture-priority AE, depth-of-field AE, E-TTL flash AE, manual, flash metered manual ISO speed range Equivalent to ISO 200-1600 (in 1/3 stop increments), ISO speed can be expanded to ISO 100 and 3200 Exposure compensation Auto exposure bracketing (AEB): +/- 3 stops in 1/3 stop increments Bracketing methods (1) Shutter speed or aperture (2) ISO speed Manual: +/- 3 stops in 1/3 stop increments (can be combined with AEB) AE lock Auto: Operates in One-shot AF mode with evaluative metering when focus is achieved Manual: By AE lock button in all metering modes Shutter Type Electronic shutter with the CCD sensor and vertical-travel, local-plane shutter with all speeds electronically-controlled Shutter speeds 1/16,000 to 30 sec. (1/3 stop increments), bulb, X-synch at 1/500th sec. Shutter release Soft-touch electromagnetic release Noise reduction for long exposure Operate at 1/15th sec. or a slower shutter speeds (including bulb), ?????? Self-timer 10-sec. or 20-sec. delay Remote control Remote switch N3-type terminal provided Flash External flash Speedlite EX series E-TTL autoflash PC terminal Provided; operates regardless of sync polarity Drive System Drive modes Single-frame, low-speed continuous, high-speed continuous Continuous shooting speed Low-speed continuous: 3 fps High-speed continuous: 8 fps Max. burst during continuous shooting 21 shots in Large/Fine, Large/Normal, Small/Fine modes 16 shots in RAW, RAW+Large/Fine, RAW+Large/Normal,RAW+Small/Fine modes *Maximum shots per burst depends on the subject shooting mode, and ISO speed. LCD Monitor Type TFT color LCD monitor Monitor size 2.0 inches Pixels Approx. 120,000 Coverage Approx. 100% with respect to the effective pixels Brightness control Adjustable to one of five levels Image Playback Image display format (1)Single image with information (2) Single image (3) 4-image index (4) 9-image index Highlight alert In display formats (1) and (2) above, any overexposed highlight areas will blink in the image display Active AF point indicator Displayed in the single image with information display format Image Protection and Erase Protection Erase protection of one image, all images in folder, or all images in the CF card can be applied or cancelled at one time. Erase One image, all images in folder, or all images in the CF card can be erased (except protected images) at one time Sound Recording Recording method The voice narration recorded with the built-in microphone is attached to the image File format WAV Recording time Max. 30 sec. per recording Menus Menu categories (1) Shooting menu (2) Image reviewing menu (3) Setup menu (4) Custom/Personal functions LCD monitor language Japanese, English, French, German, Spanish Firmware update Update possible by the user Custom functions 21, with 67 possible settings Personal functions 25, uploadable via IEEE 1394 computer connection Power Source Battery One Ni-MH Pack NP-E3 *AC power can be supplied via the AC adapter and DC coupler Number of shots At 20 °C/68 °F: approx. 500. At 0 °C/32 °F: approx. 350 When a fully-charged Ni-MH Pack NP-E3 battery and EF 50mm f/1.4 USM lens are used; the photo image confirmation function is “on”; the confirmation display time is 2 sec.; and the file format is RAW + Large/Fine) Battery check Automatic Power saving Provided, Power turn off after 1, 2, 4, 8, 15, or 30 min. Back-up battery One CR2025 lithium battery Dimensions and Weight Dimensions (W x H x D) 156 x 157.6 x 79.9 mm / 6.1 x 6.2 x 3.1 in. Weight 1250 g. / 44.1 oz. (Body only. Battery: 335 g. / 11.8 oz.) Working Conditions Working temperature range 0 – 45 °C / 32 – 113 °F Working humidity 85% or lower
